Cat6a Riser Ethernet Cable 1000ft UTP Solid Ethernet Green Spool


Out of stock



Cat6a Riser Ethernet Cable 1000ft:

Are you in need of a high-performance cable a floor to floor application? If yes, you are in the right place. Smartech Cables offers you this 1000ft category 6 augmented (or commonly referred to as cat6a) cable with riser rated CMR external jacket in green color. The cat6a riser ethernet cable 1000ft is offered at the most reasonable price, and the specifications of the cable are tested. There is a selection of jacket colors available for this cable. It is supplied in 1000’ spool, and the entire length of 1000ft is marked at every sequential foot.

The cat6a riser ethernet cable 1000ft green bulk is perfect for 10BASE-T, 100BASE-TX Fast Ethernet, 1000BASE-T (IEEE802.3), 100VG-AnyLAN (IEEE802.12), 550 MHz Broadband Video Voice, T1, ISDN 155/ 622 Mbps, and ATM PoE (Power over Ethernet). It is capacitated to transmit at high bandwidth frequencies of up to 750 MHz. And unlike the previous generations, it allows premium quality data transfer rates of 10 GB for a maximum distance of 100 meters. Likewise, this cat6a riser ethernet cable 1000ft allows 10GBASE-T and all other LAN applications to be run for a maximum distance of 100 meters. As for the capability to minimize cross talk, this cat6a riser ethernet cable 1000ft green bulk is perfect. It has tighter wounds within, and thicker sheathing on the outside which allows it to cut down cross-talks in your transmissions so that you can enjoy uninterrupted signal and data transmission even at higher frequencies or for long-distance. The cable has been tested to provide more protection against Power Sum Equal-Level Far-End Crosstalk (PS-ELFEXT), Near-End Crosstalk (NEXT) and Alien Crosstalk (AXT). What this indicates is that you will enjoy greater data integrity. There will be a less loss of data packets and you can enjoy quality transmissions with the low bit error rate and excellent attenuation.

There are four unshielded twisted pairs, and thus, eight solid conductors. The bulk has tough riser rated insulation outside. This cat6a riser ethernet cable 1000ft is perfect to be used in vertical riser-rated applications, for instance, between floors. When you are to choose the cable that should correspond to the needs of your installation site, we recommend you first check for plenum spaces. Because, for plenum spaces (which are the air handling spaces through which air circulates for the purpose of heating, cooling, ventilation and so on) you must install plenum rated cables as they are more stringent with their fire-retardant properties. As for this cable, it features self-fire extinguishing characteristics and is designed to be used in vertical applications for which it is tested for a vertical burn test. Moreover, it is suitable to prevent the spread of fire from one floor to another floor, and it is a low smoke cable which does not burn with harmful and injurious-to-health fumes.

SKU: N/A Category:
PoE: IEE 802.3af / IEEE 802.3at (PoE+)
Color: Blue, White, Yellow, and Green
Cable: Cat6a CMR O.D. 8.1 ± 0.2 mm
Conductor: O.D. 1.06 – 1.10 mm – 4 Twisted Pairs
Frequency: 750 MHz
Wire Gauge: 23 AWG
Applications: IEEE 802.3 an, 1GB, 10GBase-T and Legacy Speeds
Bending Radius: 4 x Overall Diameter
Spline Separating: 4 Pairs
>> Installation Temp: 0°C to 60°C
>> Length & Package: 1000 Feet on Wooden Reel
>> Jacket & Shielding: FEP – Unshielded
